New Products

C2



Automatic Tool Changing 8" Multiplex Turning Center



C2 is an integrated multiplex turning center that combines the processing capability of a turning center with the processing capability of a machining center obtainable through Y and C-axis control. It is capable to manufacture parts in complex geometry with a single chucking and its standard-fitted automatic tool changer enables prompt machining of parts that require many tools





주요 특장점




High Productivity (Reduced Non-cutting Time)

①  Process integrated machining (multiplex machining combined of turning and milling)

②  Quick tool change
③  Tool expandability through magazines



Enhanced Machining Stability (Machining Accuracy Maintained for a Long Time)

①  Orthogonal feed structure
②  Efficient turnmill cooling structure
③  Built-in Spindle (Main / Sub)



Reduced Operating Cost

①  Reduced installation space (3 existing machine → 1 C2)
②  Reduced machine purchase and maintenance costs





Specifications



Item

Unit

C2 YMC

C2 YSMC

  Swing over Bed

mm (inch)

Ø730

  Max Cutting Dia (Main / Sub)

mm (inch)

Ø630 (Ø24.8)

Ø630 / Ø510 (Ø24.8 / Ø20.08)

  Max Cutting Dia (Main / Sub)
  - Parts Catcher option is required

mm (inch)

Ø450 (Ø17.72)

Ø450 / Ø510 (Ø17.72 / Ø20.08)

  Max Cutting Length (Main / Sub)

mm (inch)

557 (21.93)

557 / 569 (21.93 / 22.4)

  Chuck Size (Main / Sub)

inch

8 (OPT: 10)

8 (OPT: 10) / 6

  Max Spindle Speed (Main / Sub)

rpm

5,000

5,000 / 6,000

  Through Spindle Hole Diameter (Main / Sub)

mm (inch)

Ø76 (Ø2.99)

Ø76 (Ø2.99) / Ø38 (Ø1.5)

  Spindle Motor (Main , Sub)

kW (HP)

15 / 11 (20 / 15)

15 / 11 (20 / 15) , 15 / 11 (20 / 15)

  Number of Tool Station

ea

18

  Rapid Speed (X / Z / Y / B)

m/min (ipm)

30 / 30 / 15 / 30 (1,181 / 1,181 / 591 / 1,181)

  Max Stroke (X / Z / Y / B)

mm (inch)

360 / 700 / ±60 / 705 (14.17 / 27.56 / ±2.36 / 27.87)

  Turnmill Spindle Motor

kW (HP)

5.5 / 3.7 (7.4 / 5)

  Floor Space (L x W x H)

mm (inch)

3,610  x 2,784 x 2,360 (142.13 x 109.61 x 92.91)

NC Controller

Fanuc 0i-TF







Mounting software




Lathe Hwacheon Tool Load Detect System (OPT)

"Detect and diagnose the most minute of tool-end point movement"

The Hwacheon Lathe Tool Load Detect System constantly detects and diagnoses the tool load under a process to prevent tool wear and damage, and to keep your machine and tools in optimal shape.





Monitoring Solution of Real-time Operational Status (OPT)

"Real Time Operating Status Monitoring Solution"

· Monitoring system for the User's factory machine management
· User can always check the status of the machine utilizes a smartphone
